12-25 mm /20-55 mm /50-125mm T2.8-22 Pictor PL/RF DZOFILM

Zoomer

DZOFILM 12-25 mm /20-55 mm /50-125mm T2.8-22 Pictor PL/RF

DZOFILM

12-25 mm /20-55 mm /50-125mm T2.8-22 Pictor PL/RF Black

With a minimum focusing distance of 0.4m (15.74’’), less than one arm’s length, the lens enables you to shoot tighter close-ups in limited space environments with the curvature of field being significantly controlled, creating a more subjective perspective by bringing the audiences closer to the characters and immersing them in the story.

Ref : DZO-7220001B/2B/4B-KIT

Plus de détails

6 698,70 € TTC 6698.7

5 582,25 € HT

Ajouter à la liste

Accessoires

Voir plus
Caractéristiques

A Creative Vision
Inspires Brilliant Ideas

The 12–25mm lens can capture more of the visual spectrum than human eyes can see, and the perspective effect of ultra–wide angle can draw attention to the foreground while enhancing the depth of field and tension. Additionally, the exceptional optical design makes it possible to significantly control the distortion when shooting at maximum wide-open aperture, making it ideal for creating majestic and surreal images.*

Explore
Wider Horizon

DZOFILM Pictor 12-25mm T2.8, the latest Super 35 wide-angle lens, captures wide shots with ease. Together with the Pictor 14-30, 20-55 & 50-125, forms an integrality covering all sort of scenes.

Correlated and
Sense of Space

Deeper DOF and wider FOV captures broaderwider background. Rendering the atmosphere, clearly showings the relationship among subjects, characters and surroundings. Expanding distance between objects and background, reflects the artistic sense of space.

Capturing

The distortion of wide angle lens, exaggerates emotion of characters and highlights the dramatic expression.

Visual Effect

Capturing exaggerating movement, aggrandizes the rhythm of image and enhances the
visual impact in the story.

Professional Cine Lenses with Concrete Build

DZOFILM is devoted to exploring the aesthetic of film and design of optics. Both mechanics and optics are
designed to be compact and versatile, allowing users to enjoy the smooth and precise operation and
every shooting moment with Pictor Zoom.

Parfocal Design

Center image stay sharp during zooming in or out.

No matter from close-up to wide shot, or rapidly zoom out to long shot, under Parfocal design, focus keeps still all the way along.

Minimal Breathing

Thanks to the floating structure, the breathing of Pictor Zoom lenses are negligible during focusing.

Versatile in Ultra compact

At just 1.6kg (3.5 lbs), Pictor zoom can be easily mounted on a crane, jib, tripod, ROV and other moving platforms, and provides safer and more efficient work methods by reducing heavy lifting. Be a better run-and-gun filmmaker with no fear of complicated scenes or quick shooting, save time by not changing lenses frequently, use Pictor zoom, and never miss an inspiring moment.

Gentle Sharpness & Vivid Look

From feature film, commercial, to documentary, Pictor Zoom captures crisp details
while expressing organic look and cinematic texture.

[Spot Effect]
Increases Sense of
Separation

Dreamatic Bokeh & Esthetic Transition

During the focus fall-off, 16 blades T2.8 iris generated soft bokeh. The natural transition from focus to de-focus conveys the ambiance and highlights the subject.

Speed up Your Shooting!

Consistent Design & Higher Efficiency

Highly consistent in color and mechanical control, satisfying most shooting demands. Efficient management with the consistent ergonomics of standard M0.8 gear rings. Multiple ways of mounting follow focus, speed up your shooting.

Seek for More Possibility

Interchangeable mount system
compatible with PL、EF、X、L、RF、E mounts,
provides more possibility of shooting videos.

PARAMETER

FOCAL LENGTH	12-25 mm	14-30 mm	20-55 mm	50-125 mm
colour	Black / White
MOUNT	PL / EF
T-STOP	T2.8-22
Image Circle	φ31.5mm(S35)
optical construction	21 Elements in 15 Groups	21 Elements in 17 Groups	18 Elements in 15 Groups	18 Elements in 13 Groups
Flange Distance	52mm(PL) / 44mm(EF)
CLOSE FOCUS (from sensor plane)	0.4m/1ft4in	0.6m/2ft		0.8m/2ft8in
ZOOM Ratio	2.08X	2.14X	2.75X	2.5X
Iris control	64.4°	61°	65°	72°
FOCUS control	270°
ZOOM control	100°
FRONT DIA.	φ95mm/3.74"
LENGTH	150mm(PL)5.9"/ 159mm(EF)6.26"	173mm(PL)6.81"/ 181mm(EF)7.13"	164mm(PL)6.46"/ 171.9mm(EF)6.77"	175mm(PL)6.89"/ 182.9mm(EF)7.20"
Iris blade	16
FILTER SIZE	M86*0.75
Gear Pitch	0.8 Mod
material	Aluminum Alloy
WEIGHT	≈1600g	≈1880g	≈1520g	≈1700g
