Zoom H4Essential Enregistreur 4 pistes 32 bits
Zoom
H4 Essential – Enregistreur 4 pistes 32 bits à virgule flottante - couple microphone X/Y - noir
- Enregistreur numérique 4 pistes
- 2 micros à condensateur en configuration X/Y à 90°, jusqu’à 130 dB SPL
- Deux entrées Micro/Ligne sur prise combo XLR-Jack 6,35mm
- entrée latérale Mic/Line in sur mini-jack 3,5mm
- Enregistrement sur carte microSDHC/ microSDXC jusqu’à 1TB
- Écran LCD 2’’ offrant une interface en français
- Sortie casque sur mini-jack 3.5mm stéréo
- Haut-parleur de contrôle mono 250mW/8Ω
- Fonctionne sur 4x pile LR6
REF: H4E
H4essential – Enregistreur 4 pistes 32 bits à virgule flottante - couple microphone X/Y - noir
- Enregistreur numérique 4 pistes
- 2 micros à condensateur en configuration X/Y à 90°, jusqu’à 130 dB SPL
- Deux entrées Micro/Ligne sur prise combo XLR-Jack 6,35mm avec préamplificateurs haute résolution et alimentation fantôme +48V
- entrée latérale Mic/Line in sur mini-jack 3,5mm supportant l’alimentation PiP pour les microphones lavalier
- Formats d'enregistrement : WAV 32 bit à virgule flottante, 44.1/48/96kHz
- Enregistrement sur carte microSDHC/ microSDXC jusqu’à 1TB
- Écran LCD 2’’ offrant une interface en français
- Port pour adaptateur bluetooth BTA-1 (en option) offrant le contrôle à distance via smartphone iOs et la synchronisation UltraSync blue
- Port USB Type-C de type High Speed 2.0 class compliant, compatible Mac, Pc et iOs
- Fonctions USB : Lecteur de cartes, interface audio 4x entrées/2x sorties en 24 ou 32Bits @ 44,1 ou 48kHz
- Sortie casque sur mini-jack 3.5mm stéréo
- Haut-parleur de contrôle mono 250mW/8Ω
- Fonctionne sur 4x pile LR6 (non incluses, autonomie de 10 à 20H environ en 48 kHz) ou alimentation AD-17 (en option)
Zoom 4-Track 32-Bit Float Portable Audio Recorder, 130 dB SPL XY Mic, Color LCD Screen
Ideally equipped for the burgeoning musician, indie filmmaker, and content creator, the H4essential Portable Recorder from Zoom offers four tracks of pristine, distortion-free audio without the need to set levels.
With 32-bit float recording and X/Y mics that can handle 130 dB with ease, the H4essential offers a versatile pain-free audio solution.
The dual XLR-1/4" combo inputs feature low-noise and high-quality Zoom mic preamps and sport +48V phantom power for driving professional condenser mics.
An onboard mixer is easy to use with the bright 2" color display to adjust individual tracks and directly view waveforms in real time.
The H4essential can utilize its USB-C port not only for power but also to stream up to two channels of audio to computers and smart devices, acting as a 4-in / 2-out interface. Furthermore, the recorder is tripod mountable, allowing it be conveniently used in a fixed location or atop a camera via an adapter for field recording duties.
° Equipped with Accessibility Options
The Essential Series was designed with accessibility for the visually impaired.
Navigate the menu with audible descriptions through the built-in speaker or headphones.
Creators can choose English, Spanish, French, Japanese, German, Italian, or Chinese.
° Sound Pressure Level
The 2 XLR/TRS combo inputs feature Zoom's ultra-clean preamps that supports phantom power and +4dBu professional line level input.
The onboard X/Y microphones can capture sound up to a thunderous 130 dB SPL, equivalent to a rock concert.
° Record and Stream
Stream in 32-bit float while simultaneously recording to an SD card.
When connected to a PC, Mac, iOS, or Android device using the USB-C port, the H4essential can be used as a 4-in/2-out audio interface.
° Bluetooth Timecode
With the BTA-1 Bluetooth Adapter you can also pair with Bluetooth timecode devices for audio and video sync.
- 4-track 32-bit float recorder with Dual A/D Converters
- Clip-free recording with no need to set gain
- Records up to 96kHZ sample rate
- Color LCD Screen
- 130 dB SPL XY Mic
- 2 XLR/TRS combo inputs with locking connector
- 3.5mm mic/line input for lavalier mics and line level sources
- Built-in mixer to adjust each track's audio level
- Built-in speaker for quick reference playback
- 3.5mm line output for headphones or to connect to a camera
- Voice Guidance accessibility for the visually impaired
- 32-Bit Float audio interface for PC, Mac, iOS, and Android devices via USB-C port
- Use as an interface and record to SD card simultaneously
- Record to SD cads up to 1TB
- 10 hours of battery life on AA battery (2x) or USB-C Bus Power
Portable Recorder
Form Factor: Handheld Recorder
Primary Use Applications:
Audio-for-Video, Dictation & Transcription, Music Recording, Podcasting
Number of Tracks: 4
Number of Input Channels: 5 (3 x Mono, 1 x Stereo)
Maximum Sampling Rate: 96 kHz / 32-Bit Float
Microphone: Built-In Cardioid Condenser Stereo Pair, X/Y Configuration
Number of Microphone Inputs: 3
Built-In Speaker: Yes, 1 W Mono
Display: 2" / 5.1 cm Monochrome OLED
Memory Card Support: microSDXC (Up to 1 TB)
Internal Storage: No
Special Features: Overdubbing
Recording
Audio File Formats: BWF, iXML, WAV
Sample Rates: 44.1 / 48 / 96 kHz
Bit Depth: Up to 32-Bit (Floating Point)
Timecode Support: No
Included Software: No
Connectivity
Analog I/O:
2x Combo XLR-1/4" 3-Pin Female Balanced/Unbalanced Line/Mic Input (Lockable)
1x 1/8" / 3.5 mm TRS Female Balanced/Unbalanced Line/Mic Input
1x 1/8" / 3.5 mm TRS Female Headphone/Line Output
Digital I/O: No
Phantom Power: +48 V
Phantom Power Current: 10 mA (Max)
System Connection: 1x USB-C (I/O, 2.0)
Audio Interface Capability: Stereo Only
Wireless: No
Mobile App Compatible: No
Performance
Max Input Level:
- Mic Inputs: +4 dBu
- Line Inputs: +24 dBu
Headphone Output Power: 20 mW per Channel into 32 Ohms
Impedance: Outputs: less than or equal 15 Kilohms
Microphone Sensitivity: -43 dB (X/Y)
Microphone Max SPL: 130 dB SPL (X/Y)
Power
Power Options: Battery, USB Bus Power, AC/DC Power Adapter
Battery Type: 2x AA
Approximate Battery Life:
- 9 Hours (AA Alkaline, Recording, Built-In Mic)
- 14 Hours (AA NiMH, Recording, Built-In Mic)
- 20 Hours (AA Lithium, Recording, Built-In Mic)
AC/DC Power Adapter: 5 VDC at 1 A (Included)
Physical
Dimensions: 2.6 x 1.5 x 6.1" / 6.7 x 3.8 x 15.6 cm
Weight: 8 oz / 226 g (with Batteries)
Type | Portable |
